Vickers and Knoob FV-810 Hardness Testers

 .

The FV-800 Series performs precise measurements of Vickers (HV), Knoop (HK), Brinell (HB), and fracture toughness (Kc) quickly and easily, with one-touch selection via the touchscreen panel.

Equipped with a USB output port, as well as cylindrical/spherical compensation and sample thickness calculation functions.

 .

ADVANCED TOUCHSCREEN DISPLAY AND OPERATION .

• Clean, user-friendly touchscreen integrated with a highly advanced PC board.


• Measurement procedures, conditions, and data are clearly displayed. (FV-810 Series)

.

BRINELL TESTING.

• Accurate low-load Brinell testing is available as a standard function.


• An optional accessory, “Ball Indenter φ1–5 mm,” is required. (FV-810 Series).

.

FRACTURE TOUGHNESS TESTING (Kc)

• Kc values can be measured as a standard function in accordance with the JIS R1607/IF method.

• Combined with Vickers and Knoop values, it is highly effective for evaluating new material quality. (FV-810 Series).

 .

CLEAR VIEW AND EASY MEASUREMENT

• A newly developed illumination system with interchangeable aperture diaphragm and field aperture provides enhanced resolution at both high and low magnifications.

• Easily replaceable color filters further improve image clarity. (All series).

.

VISTA CLARA Y MEDICIÓN FÁCIL

• El diafragma de apertura cambiable y la apertura de campo con un mecanismo de fuente de luz recientemente desarrollado proporcionan más resolución tanto en aumentos altos como bajos.
• El filtro de color fácilmente cambiable proporciona más resolución. (Todas las series).

.

4 OBJECTIVE LENSES (OPTIONAL)

• The new turret mechanism allows the use of up to four objective lenses, enabling observation of a wide sample area.

• Different magnifications can be quickly selected by rotating the turret.

• Proper objective selection ensures more precise and repeatable indentation placement and measurement. (FV-810 Series).

.

2 INDENTERS FOR HV/HK MEASUREMENTS (OPTIONAL)

• The new turret mechanism supports two indenters simultaneously.

• This allows Vickers and Knoop testing without the need to change the indenter. (FV-810 Series)



   (Agrandar)

Return to Hardness Testers and Accessories ←   Future-Tech Hardness Testers←  Microhardness Testers | Vickers Hardness ←

Vickers and Knoob FM-810 Hardness Testers

The FM-810e and FM-810 Series perform precise measurements of Vickers (HV), Knoop (HK), Brinell (HB), and fracture toughness (Kc) quickly and easily, with one-touch selection via the touchscreen panel.

 .

USB OUTPUT

• Equipped with a USB port for data output, along with cylindrical/spherical compensation and sample thickness calculation functions.

ADVANCED COLOR LCD TOUCHSCREEN DISPLAY AND OPERATION.

• Color LCD touchscreen panel integrated with a highly advanced PC board.

• Measurement procedures, conditions, and data are clearly displayed. (FM-810 Series)

.

BRINELL TESTING

• Accurate low-load Brinell testing is available as a standard function.


• An optional accessory, “Ball Indenter φ1 mm,” is required. (FM-810 Series)

 .

FRACTURE TOUGHNESS TESTING (Kc)

• Kc values can be measured as a standard function according to the JIS R1607/IF method.

• Combined with Micro Vickers and Knoop values, it is highly effective for evaluating new material quality. (FM-810 Series)

 .

CLEAR VIEW AND EASY MEASUREMENT

• A newly developed illumination system with interchangeable aperture diaphragm and field aperture provides enhanced resolution at both high and low magnifications.

• Easily replaceable color filters further improve image clarity. (All series)

 .

WIDE RANGE OF SELECTABLE TEST LOADS

• Test loads can be freely selected from a wide range, allowing customized load combinations. (Optional / configurable).

 .

X-Y COORDINATE DISPLAY

• Stage coordinates are displayed on-screen when linked with the optional digital micrometer head.

 .

4 OBJECTIVE LENSES (OPTIONAL)

• The new turret mechanism supports up to four objective lenses, enabling observation of a wide sample area.


• Different magnifications can be easily selected by rotating the turret.


• Proper objective selection ensures more precise and repeatable indentation placement and measurement. (FM-810 Series).

 .

2 INDENTERS FOR HV/HK MEASUREMENTS (OPTIONAL)

• The new turret mechanism allows two indenters to be mounted simultaneously.

• Enables Vickers and Knoop testing without changing the indenter. (FM-810 Series)

 .



   (Agrandar)

Return to Hardness Testers and Accessories ←   Future-Tech Hardness Testers←  Microhardness Testers | Vickers Hardness ←

FM-LX Microhardness Testers

 .

By adopting a load cell system, multi-step load switching is enabled.

The load switching operation has evolved from a conventional dial to a smooth touchscreen operation.

Any test load can be selected at the time of order (within the minimum to maximum load range).

Equipped with a hardness conversion function, allowing HV measurement results to be simultaneously displayed in other scales on the front panel.

BUILT-IN CAMERA MECHANISM

• Features independently developed automatic indentation with high-performance dedicated software and PC-based measurement.
• When the measurement microscope is removed, the system offers a renewed configuration.

• (R-type with automatic indentation reading function)

LOAD CELL FORCE TESTING

• In addition to the conventional dead weight method, models equipped with load cell-based force application and multi-step load switching achieve high accuracy.

• Supports a wide load range from 50 gf to 10 kgf, suitable for various testing applications. (FM-LX Series)

.

• TILTED TURRET

• The inclined turret design reduces the risk of contact between the sample and the indenter/objective lens during rotation.
• .

INFINITY-CORRECTED OBJECTIVE LENSES

• In addition to the two standard lenses (×10 and ×50), up to five lenses can be installed simultaneously (optional).

• Enables a wide range of observation and measurement, from low to high magnification.

.

DUAL INDENTERS

• Standard: 1 Vickers (HV) indenter

• Optional: Vickers (HV) / Knoop (HK) / Brinell (HB)

• Up to two different indenters can be installed simultaneously.

.

CAPACITIVE TOUCH PANEL

• The main display screen can be changed with a simple swipe.

• The capacitive touchscreen ensures smooth and responsive operation.

• Measured data can be directly transferred to a PC via the main unit output port, eliminating operator recording errors.



   (Agrandar)

Return to Hardness Testers and Accessories ←   Future-Tech Hardness Testers←  Rockwell Hardness Testers← Rockwell Hardness Testers←

Rockwell FR-X Series Hardness Testers

  ......

Future-Tech has achieved the highest level of accuracy and outstanding reliability through a completely new design and uncompromising precision manufacturing.

With the adoption of a stealth-type dual information panel, both visibility and operability have been significantly enhanced.

  .

EMPHASIZED HIGH PRECISION

• The popular FR-e series has been redesigned to achieve superior precision performance.

REINFORCED FRAME

• Significant improvement in hardness measurement has been achieved through a newly designed rigid frame.


• A maximum sample height of 255 mm is available, along with a long-type version of 401 mm
  (from the horizontal anvil to X3 and X3L).

STABLE LOAD SHAFT MECHANISM

• A highly sensitive load shaft with upper and lower ball guides prevents lateral displacement.

• Ensures stable hardness measurement on cylindrical and spherical surfaces.

STANDARD COMPENSATION FUNCTION

• Low, medium, and high multi-point compensation to comply with various standards.


• Provides test results that meet different standards across all hardness ranges.

SHAPE COMPENSATION FUNCTION

• Achieve standard-compliant test results by inputting the diameter of spherical or cylindrical samples.

MAXIMUM INDENTER DEPTH DISPLAY

• Displays the maximum indenter depth along with the test result.


• Allows evaluation of material elasticity based on hardness values.

STEALTH-TYPE DUAL INFORMATION PANEL

• Displays various data including OK/NG judgment and conversion values alongside measurement results.


• (Test load application/release and hardness indication are fully automatic)

DATA JUDGMENT FUNCTION

• Displays measurement evaluation (HI / OK / LO) by setting upper, lower, and average values on the secondary information panel.

LED ILLUMINATION

• Provides excellent visibility of the specimen in low-light environments and enables precise positioning.

USB DATA OUTPUT

• Equipped with USB (B2.0) interface.

• Supports data transfer to PC (optional).

• Complies with ASTM (E-140) and SAE (J-417b) standards.
