Return to Universal Testing Machines ←  Horizontal Testing Machines (AJT)←

High-Capacity Horizontal Tensile Testing Machine

All AJT testing machines are designed and manufactured according to customer specifications, specifically for simple load testing, destructive testing, cyclic testing, and long-duration load testing of all types of materials (optional gripping fixtures available).

 .

Operator usability and safety are always at the forefront of every AJT design, ensuring compliance with all relevant machinery directives and standards:

.

1. The machine can be supplied with manually or hydraulically operated safety enclosures, incorporating coded magnetic interlock switches. This ensures that the machine remains in a safe condition while operators are preparing it for testing.

2. The horizontal tensile testing machine model has proven to be the most popular design among our customers. It offers the capability to perform proof load testing, destructive testing, and long-duration cyclic testing of samples across a wide range of industries.

3. Using a modular construction, the machine can be manufactured to any required length and extended at a later date if necessary.

   A traveling carriage is included, providing the advantage of multiple test lengths along the entire length of the machine.

4. The operator control system can range from simple manual operation to PLC or fully PC-controlled systems, each with the option of additional data acquisition for product verification and certification.

5. All AJT testing machines are equipped with our in-house manufactured load cell, mounted on the tension fork, featuring a multi-bridge strain gauge, temperature compensation, and sealed zero balance, calibrated in accordance with ISO 7500-1:2004.

•  AJT has supplied machines of this type with capacities ranging from 5 tons (11,000 lbs) up to 2000 tons (4,400,000 lbs) of force.

AJT horizontal tensile testing machines are available in the following models: 174E (manually controlled), 177PC (PC-controlled), and 177PLC (PLC-controlled).

They are available in various lengths, widths, heights, and capacities to meet your company’s specific testing requirements.

Flat Tension Testing Machine – 174 e		Flat Tension Testing Machines – 177
Specifically designed for simple load testing, including testing of wire ropes, chains, cables, and similar components. Power Unit: Long-stroke hydraulic cylinder with double-acting ram.  Piston head and cylinder ends fitted with low-friction seals.    Load Control Console: Digital display with 20 mm high-visibility characters, connected to the load cell via a shielded multi-core cable.  Peak hold (freeze) function to capture the maximum applied load before reset. Pressure control achieved באמצעות a control valve located at the operator’s position.  START and STOP buttons.  Optional data acquisition system displaying load and extension. Load Cells: Positioned between the load and the ram Tension load gauge incorporating a multi-bridge strain gauge system, temperature compensation, and sealed zero balance.  Calibrated in accordance with International Standard ISO 7500-1:2004  . .  .     (Agrandar)	.......	. Specifically designed to meet customer requirements for simple load testing, destructive testing, cyclic testing, and long-duration load testing of all types of materials (subject to optional gripping configurations).  . Power Unit: Long-stroke hydraulic cylinder with double-acting ram Piston head and cylinder ends fitted with low-friction seals.    Load Control Console: Fully computerized system. Data acquisition capabilities. Records load, time, extension, and related data.   Load Cell: Accuwacy™ with manual readouts, made from lightweight aerospace alloy.        (Agrandar)

Artec Space Spider - Portable Scanner

Reverse Engineering, Quality Control, Product Design, and Manufacturing

.  .   Technical Specifications:   HD Mode: N/A   Hybrid geometry and texture tracking   Data processing algorithms based on geometry and texture   Working distance: 0.2 – 0.3 m   Volume capture zone: 2,000 cm³   Linear field of view, Height × Width @ closest range: 90 × 70 mm   Linear field of view, Height × Width @ farthest range: 180 × 140 mm   Angular field of view Height × Width: 30 × 21°   Texture capture capability   Texture resolution: 1.3 MP   Colors: 24 bpp   3D reconstruction rate for real-time fusion: up to 7.5 fps   3D reconstruction rate for 3D video recording: up to 7.5 fps   Data acquisition speed: up to 1 million points/sec   3D exposure time: 0.0002 s   2D exposure time: 0.0002 s   3D light source: Blue LED   2D light source: 6 white LED array   Display / touchscreen: USB streaming through external computer   Compatible operating system: Windows 7, 8, or 10 x64   Recommended hardware requirements: Intel Core i7 or i9, 32 GB RAM, GPU with 2 GB VRAM   Minimum hardware requirements: Intel Core i5, i7, or i9, 18 GB RAM, GPU with 2 GB VRAM

Science, Art, Design, Education, Healthcare, Industrial Design, and Manufacturing   Artec Studio software includes Autopilot, which expertly guides you through the entire post-processing workflow and automatically selects the best algorithm for your data, allowing you to watch your high-precision model come to life before your eyes. An advanced intelligent mode guides users through scanning and data processing in just a few simple steps   Answer a few simple questions about the object you scanned, and Artec’s advanced 3D imaging software will select the most effective 3D algorithms for your data and generate a high-precision model ready for professional application.

Return to Universal Testing Machines ←  Horizontal Testing Machines (AJT)←

Load Cells with sustainable reading Handheld

Handheld Plus is a rugged and versatile portable digital display. It offers a wide range of features and is compatible with all Crosby | SP load cell products.

.

Handheld Plus Features:

• • Ergonomic design
  • Powerful PCB delivering industry-leading features
  • User-selectable units of measurement (tons, pounds, kg, and kN)
  • Peak hold function
  • Preset tare
  • User-resettable overload counter (HHP and SW-HHP)
  • Programmable audible overload alarm (HHP and SW-HHP)

 .

This overload alarm counter is a critical requirement for many safety and quality control departments, as it tracks overload events. This allows the load cell to be immediately removed from service after an overload event that could affect calibration. The load cell can then be properly tested and, if necessary, recalibrated before being returned to service.

 .

The HHP is suitable for wired connection to any Straightpoint wired load cell product and can also be easily adapted to load cells from other manufacturers with an mV/V output.

In addition to the standard HHP, the SW-HHP is designed for connection with any Straightpoint wireless load cell. It offers a range of up to 1000 m / 3280 ft (ATEX: 700 m / 2300 ft) and is supplied as standard with the Radiolink Plus load cell.

 .
