ITD Series Impact Testers

Charpy Impact Pendulums - Izod Computerized, Wireless and Touchscreen

.

Precision, technology, and total control in every impact test

🧪 General Description

The ITD Series Impact Testers are designed to perform Charpy and Izod tests on metallic and plastic materials with high impact energy and extreme precision.

They feature a robust design, high-resolution electronic measurement system, and a digital control system that ensures repeatability, safety, and accuracy in every test.
Their structure allows testing of a wide range of materials under controlled conditions in compliance with international standards.

The ITD series impact testers provide digital test result readings through a remote LCD display. In this model, the pendulum is automatically raised and released.

⚙️ Main Features

• Energy capacity: up to 750 J, depending on configuration.
• Test type: Charpy and Izod (with quick accessory change system).
• Control system: automated PC-based system with ImpactStar software.
• Measurement system: high-precision optical encoder.
• Operating modes: manual, semi-automatic, or fully automatic.
• Interface: LCD touchscreen or PC control.
• Construction: high-rigidity steel frame with excellent stability and low vibration levels.
• Standards compliance: ASTM E23, ISO 148, EN 10045, DIN 50115, and GOST 9454.

🧩 Standard Accessories for the 750 J Model

• ImpactStar software with PC and digital interface.
• 300 J, 500 J, and 750 J hammers.
• Interchangeable grips (V and U types).
• Specimen support and centering system.
• Automatic pendulum release device.
• Tool kit and anchor bolts.
• Safety guard with electromagnetic locking system.

🧱 Advantages

• High precision and repeatability in impact testing.
• Full parameter control through software.
• Ergonomic and safe design for the operator.
• Automatic recording of absorbed energy and impact curves.
• Ideal for quality control laboratories, universities, and research institutes.

---

   (Agrandar)

Charpy Impact Notcher L71-UV

Prepare V- or U-Type Impact Specimens with high precision, low noise operation, and compliance with ASTM, ISO, and DIN standards.

.

⚙️ Main Features

• Designed to machine notches in a single pass, in accordance with the national standard GB/T229-1994 “Test Method for Metallic Materials – Charpy Impact Notch”.
• High notch machining precision.
• Long-life hardened blades with easy replacement system.
• Quiet operation with low maintenance requirements.
• Long service life and attractive industrial design.
• Transparent safety guard for operator protection.
• Robust construction with stable movement and vibration-free operation.

 🧰 Technical Specifications

 🧩Standard Accessories

• Interchangeable V- and U-type blades.
• Safety guard.
• Specimen clamping system.
• Operation and maintenance manual.

 📏 Applicable Standards

• GB/T229-1994
• ASTM E23
• ISO 148
• DIN 50115 / ISO 83

• 💡 Advantages

• Uniform and repeatable notch preparation.
• Single-pass cutting operation.
• High rigidity, durability, and precision.
• Easy operation and maintenance.
• Compatible with PTS and LabTest Charpy impact testers.

---

   (Agrandar)

ITC-50-LTCI Low-Capacity Impact Tester

.

The ITC-50-LTCI model with a 50 Joule capacity is a computerized low-temperature machine capable of performing Izod and Charpy tests.

The unit is computer-controlled and uses ImpactStar Software.

The system can automatically calculate test results and features a storage capacity of 5,000 data records, which can be accessed at any time.

DWI-750 Low Capacity Impact Tester

.

The DWI-750 model is a Drop Weight Impact Tester designed to evaluate the impact resistance of plastic and composite materials under controlled conditions.

This equipment determines how a material reacts to a rapid impact load, simulating real-life usage conditions or impact-related failures.

⚙️ Main Features

• • Test type: Free-fall drop weight impact test.
  • Energy capacity: Variable through the addition or removal of interchangeable weights.
  • Drop height: Programmable, allowing precise adjustment of the desired impact energy.
  • Velocity measurement: Data acquisition system using an infrared (IR) optical sensor to record the actual impact velocity, automatically controlled by the software.

Applicable Standards:

• ASTM D3763
• ASTM D4272
• ASTM D5628
• ISO 6603-2, ISO 179-2, ISO 7765-2

🧰 Hammer and Anvil System

• • Interchangeable hammer designed according to testing standards.
  • Easy replacement of hammer geometry (different tip shapes).
  • Adjustable and replaceable anvil depending on the test type or material.

 🔩 Speciemn Support

• • Base with threaded holes for securing different supports or specimen holding fixtures.
  • Pneumatic clamping system with a 76 mm diameter opening, compatible with ASTM D3763 testing requirements.

 🖥️ Operational Advantages

• • • Precise control of impact energy and velocity.
    • Easy setup for different materials and thicknesses.
    • High repeatability and reliability of test results.
    • User-friendly software for data acquisition and analysis.

 📘 Applications

Ideal for:

• • Plastic quality control laboratories.
  • Composite material research centers.
  • Universities and technical education centers.
  • Automotive, aerospace, and packaging industries.
